BOGEN supports you solving your measurement or motion control task. BOGEN creates a solution based on your requirements combining a magnetic measurement head and the application specific magnetic scale.

BOGEN delivers a large variety of magnetic measurement heads for diverse applications. Whether you are looking for incremental or absolute measurement or linear or rotary measurement.

> Vendor Website





Sensing Heads

BOGEN offers magnetic measurement heads for many different applications: BOGEN adapts the magnetic sensing heads precisely from a diverse product portfolio to your customer specific requirements. The sensing heads are offered for different resolutions and frequencies.

Incremental Magnetic Sensing Heads IKS8

IKS8 sensing head

  • For linear and rotary scales
  • Non-contact measurement
  • Quick positioning
  • Highly precise measuring
  • Programmable with PC or App

Datasheet IKS8



Incremental Magnetic Sensing Head IKS9

IKS9 sensing heads

  • For linear and rotary scales
  • Small Design
  • Highly precise measuring
  • Programmable resolutions
  • Programmable with PC or App

Datasheet IKS9



Incremental Magnetic Sensing Heads

IKS11 Sensing head

  • For linear and rotary scales
  • Extra small
  • Highly precise measuring
  • Unlimited measuring length
  • ABZ

Download IKS11



Absolute Magnetic Sensing Head AKS16

AKS16 sensing head

  • For linear and rotary scales
  • Non-contact measurement
  • 16-18 Bit resolution
  • Radial or axial reading capability
  • Protection class IP67

Datasheet AKS16





Absolute Magnetic Sensing Head AKS17

AKS17 sensing head

  • For linear and rotary scales
  • Non-contact measurement
  • 19-22 Bit resolution
  • Radial or axial reading capability
  • Protection class IP67

Datasheet AKS17



Magnetic Sensing Head Linear Absolute SLA2

SLA2 sensing head

  • Magnetic sensor 14 bit for measurement of absolute position
  • For linear scale16-18 Bit resolution
  • Non-contact, quick position measurement
  • Protection class IP67

Datasheet SLA2



Magnetic Scales

BOGEN produces magnetic scales for a big variety of different applications. Depending on your requirements, you can select from a large product offering linear and rotary magnetic scales. BOGEN can produce any magnetic pole pattern on many different scales. The scales can be one track or multiple tracks and using different accuracy classes scales can be tailored to the requirements.

Linear Magnetic Scale Incremental

LMSI

  • Different scale geometries
  • Different pole pitches
  • Optional with reference
  • A variety of magnetic materials

Datasheet LMSI



Linear Magnetic Scale Aboslute

LMSA

  • Different scale geometries
  • Different pole pitches
  • No attrition from usage
  • A variety of magnetic materials
Datasheet LMSA

Linear Magnetic Scale Nonius

LMSN

  • Different scale geometries
  • Master and nonius tracks
  • No attrition from usage
  • A variety of magnetic materials
Datasheet LMSN

Rotary Magnetic Scale Incremental

RMSI

  • Customizable for many applications
  • Axial and radial magnetization
  • Optional with reference
  • A variety of magnetic materials
Datasheet RMSI

Rotary Magnetic Scale Absolute

RMSA

  • Customizable for many applications
  • Axial and radial magnetization
  • Different pattern configurations
  • A variety of magnetic materials

RMSA information

Rotary Magnetic Scale Nonius

RMSN

  • Customizable for many applications
  • Axial and radial magnetization
  • Master and Nonius Tracks
  • A variety of magnetic materials
Datasheet RMSN



Linear Magnetic Scale Bar Incremental

LMSBI

  • Very high accuracy
  • One or multiple track magnetization
  • Different scale geometries
  • Customizable for many applications
Datasheet LMSBI







Precise Motion & Control is a Bogen authorized distributor serving Florida, Puerto Rico and the Caribbean.
